NX M15-A MK II
ACTIVE TWO-WAY MONITOR
The NX 12-SMA is equipped with new high power 700 W digital amplifier and a newly designed 12” coaxial neodymium transducer that guarantees outstanding audio quality and definition as well as an extremely lightweight of the final system.
The NX 12-SMA can be also used as a , thanks to the rugged powder coated steel pole mount installed on the side. In order to control the response of the speaker in such different applications, RCF has incorporated two special Equalization Modes:
– Floor, for stage monitoring;
– Free Field, for the use of the speakers as a stand-alone PA system.
Cabinet is made in Baltic Birch plywood, finished with an extremely resistant paint for an extensive use on the road.
An ergonomic side handle, integrated with the input panel, is provided for an easier transport of the speaker.
- 750 Watt digital amplifier
- 132 dB max spl
- 90 x 40, Wide dispersion constant directivity angle, rotatable horn
- 15″ woofer, high power 3.5″ voice coil
- 1″ HF driver, titanium dome, 1.75″ voice coil
- PFC power factor correction
- Frequency Response -3 dB: 50 Hz ÷ 20000 Hz
- Max SPL: 132 dB
- Horizontal coverage angle: 90°
- Vertical coverage angle: 40°
- Compression Driver: 1″, 1.75″ v.c.
- Woofer: 15″, 3.5″ v.c.
- Input signal: bal / unbal
- Input connectors: Combo xlr-jack
- Output connectors: xlr
- Input sensitivity: -2 dBu / +4 dBu
- Crossover frequencies: 1700 Hz
- Protections: Thermal, rms
- Limiter: Soft peak limiter
- Controls: Volume, side / floor, contour
- Total power: 1500 W PEAK
- High frequencies: 500 W PEAK
- Low frequencies: 1000 W PEAK
- Total power: 750 W RMS
- High frequencies: 250 W RMS
- Low frequencies: 500 W RMS
- Cooling: Convection / forced
- Connections: Powercon in / out
- Cabinet Material: Balitc birch
- Hardware: 6 x fly tracks
- Handles: 2 side
- Pole Mount/Cap: Yes
- Colour: Black
- Height: 736 / 28.97 mm/inch
- Width: 430 / 16.92 mm/inch
- Depth: 395 / 15.55 mm/inch
- Net Weight: 29 / 63.93 kg/lbs
